Technical Specifications of the CLW 3cbm Milk Tank Truck：
| Vehicle Description | Brand | CLW |
| GVW(kg) | 4495 |
| Curb Weight(kg) | 2380 |
| Overall Dimension(mm) | 5160*1900*2090 |
| Wheelbase(mm) | 2930 |
| Axle Load(kg) | 1700/2795
|
| Top Speed(km/h) | 89 |
|
| Chassis Model | SC5021XXYVQ6B1 |
| Cabin | Single,LHD,with A/C |
| Engine | Model | CY4102-C3D |
| HP | 109 |
| Emission Standard | Euro 3 |
| Displacement/Output(ml/kw) | 3856/80 |
| Fuel Type | Diesel |
| Rate Speed(rpm) | 2800 |
| Maximum Torque(N·m) | 300 |
| Maximum Torque Speed(rpm) | 1400-1800 |
| Gearbox | 6Forward/1Reverse Gear |
| Tyre | 185R15LT 8PR |
|
| Fuel Tank | tank Capacity | 1.4000 liters to 10000 liters |
| 2.12000liters to 20000 liters |
| Tank shape | Oval shape |
| Fuel tanker size | 3500x1800x1350 |
| 5500x2000x1450 |
| Tank material | Mild steel/Stainless steel/Aluminium alloy |
| Standard equipment | With oil pump, oil loading and discharging system. Equipment opting China standard or EURO or US standard..The tank could be separated several compartment. |
| Also could modify in refuel or transport fuel tank truck. |
Product Description：
The thickness of the external insulation layer of the tank body is 120mm. The materials of the side and rear protections are all Q235. The side and rear protections are connected to the vehicle body by bolts. The cross-sectional dimensions (height × width) of the rear lower protection are 100mm × 50mm, and the ground clearance is 380mm. Optional new grille and new front combination lamps are available according to the chassis. Optional side door logo. Optional front grille and LOGO sign. The vehicle in ready condition is equipped with: spare tire, standard spare parts, coolant, and cleaning fluid.
