Production Description:
The material of the side protection and rear protection devices is Q235B carbon steel. The side protection is welded to the bottom of the box. The rear protection device is welded to the frame. The rear protection section size (mm): 140×50. The ground clearance is 500mm.
Optional parts for the cab include the front grille and side window glass. The three decorative lights in the middle of the cab roof, front fog lights, and the front spoiler of the cab are all optional. Optional wheel rim styles can be selected according to the chassis. Optional battery, urea tank, and air reservoir installation positions on the left and right. When a tailgate is selected, the material of the lower rear protection is Q235A carbon steel. The connection method is welding plus bolt connection. The section size (width × height) (mm): 50×120.
The ground clearance is 500mm. The horizontal length of the tailgate in the retracted state is 300mm. The weight of the tailgate is 440kg. This vehicle is equipped with disc brakes on the front wheels, a front-mounted exhaust pipe, and a tire burst emergency protection device on the steering wheels. The rear axle of this vehicle adopts an air suspension.
Main Technical Parameters：
| Vehicle Description | Brand | CLW |
| GVW(kg) | 18000 |
| Curb Weight(kg) | 6700 |
| Loading Weight(kg) | 11105 |
| Overall Dimension(mm) | 8600x2550x3130 |
| Wheelbase(mm) | 4700 |
| Axle Load(kg) | 6500/11500 |
| Top Speed(km/h) | 90 |
|
| Chassis Brand | DongFeng |
| Chassis Model | DFH1180EX9 |
| Cabin | Single,LHD,with A/C |
| Engine | Model | B190 33 |
| HP | 190 |
| Emission Standard | Eu 3 |
| Displacement/Output(ml/kw) | 5900/140 |
| Fuel Type | Diesel |
| Rate Speed(rpm) | 2500 |
| Maximum Torque(N·m) | 640 |
| Maximum Torque Speed(rpm) | 1500 |
| Gearbox | 6Forward/1Reverse Gear |
| Tyre | 11.00R22.5 16PR |
|
| Dump | Box Dimension(mm) | 6200x2350x600 |
| Box | Manufacturers | ChengLi Special Automobile Co.,Ltd |
| Volume(cbm) | 8.7 |
| Configuration(mm) | side:3,bottom:4 |
| Material | Carbon steel |
| Side Door | According to costomer |
| Cabin | Brand | DongFeng |
| Model | Flat proof |
| Seat | 3 |
| Color | According to costomer |
