Main Technology Parameter
| Vehicle Description | Brand | CLW |
| GVW(kg) | 18000 |
| Curb Weight(kg) | 11000/11800/12460 |
| Loading Weight(kg) | 6870/6805/5410/5345/6070/6005 |
| Overall Dimension(mm) | 9350,8850,8550,8250,8050,7750,7500, 7350
×2480,2500,×3130,3080,3100 |
| Maximum height of suction cup off the ground(mm) | 220 |
| Front Axle(mm) | 1400 |
| Rear Axle(mm) | 2150 |
| Top Speed(km/h) | 89 |
|
| Chassis Description | Chassis Brand | DongFeng |
| Chassis Model | EQ1045SJ16DC |
| Wheelbase(mm) | 3800 ,3950 ,4200 ,4500 ,4700 ,5000 ,5300 ,5800 ,5600 ,5100 |
| Traction Type | 4X2 |
| Engine Brand | DongFeng |
| Engine Model | B6.2NS6B230 |
| Emission Level | Eu 3/6 |
| Displacement/Output(ml/kw) | 6700/169 |
| Horsepower | 230 |
| Fuel Type | Diesel |
|
| High-Pressure Cleaning | Water Pressure(Mpa) | 10 |
| Water Pump Flow(L/min) | 142 |
|
| Suction Sweep Operation | Cleaning Efficiency | ≥95 |
| Maximum Suction Particle Size(mm) | 50 |
| Operating Width(mm) | 3200 |
| Sweep Tray Overhanging Dimensions(mm) | ≥400 |
| Operating Speed(km/h) | 3.5-15 |
|
| Water Tank | Water Tank Volume(m³) | 9.5 |
|
| Dust Bin | Dust Tank Volume(m³) | 7 |
| Dump Bin Tilting Angle | ≥50 |
|
| Hydraulic System | Type | Electrical Control,Drive Motor |
| Drive Motor Brand | Bosch |
| Model | 7.1 |
| Power output(kw) | 65 |
|
| High-Pressure Water System | Type | Piston Pump |
| Brand-Model | Pinfl-PT40 |
| System Pressure(Mpa) | 10 |
| Rotaional Speed(r/min) | 1450 |
| Water Valve Type | High-Pressure Pneumatic Ball Valve |
Working Effects:
Washing of Curbs and Vertical Surfaces of Curb Stones:
It can conduct comprehensive and meticulous cleaning of the edges of the road and the vertical surfaces of the curb stones, remove dirt and dust, and improve the cleanliness.
Dust Suppression by Rear Spray:
During driving, it sprays fine water mist to the rear, reducing dust and pollution, improving air quality, with remarkable effects in dry and dusty environments.
Low-Pressure Flushing:
It uses water flow of lower pressure to gently flush the road surface, removing loose dirt and debris and preparing for high-pressure cleaning without causing damage to the road surface.
High-Pressure Cleaning:
As a core function, it uses powerful pressure water flow to remove stubborn stains and oil stains, making the road surface look new, applicable to both asphalt and cement pavements.
Fixed-Point Flushing Device in Front of the Vehicle:
It can conduct precise flushing on specific areas as needed, such as hard-to-clean corners, oil stain points, and stains near traffic signs to improve the cleaning effect.
Self-Cleaning Function of the Garbage Bin:
After completing the garbage collection task, it can automatically clean the inside of the bin to remove residual garbage and dirt, prevent odors and bacteria, maintain cleanliness and hygiene, and prolong the service life.
