Dongfeng
CLW
CLW5180GC22
Technical Specifications of the CLW Group 10cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Group Dongfeng 4x2 10cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Weights | |
| GVW(kg) | 18000 |
| Rated payload weight(kg) | 7295 |
| Curb weight(kg) | 10510 |
| Dimensions | |
| Wheelbase(mm) | 5000 |
| Overall Dimension(mm) | 9330*2500*3300 |
| Max speed(km/h) | 95 |
| Engine | |
| Engine model | B170 33 |
| Emission standard | Euro 3 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 5.9 |
| Max. output (kw) | 125(170hp) |
| Drive Line | |
| Transmission | DongFeng Brand DF6S900; 6 forwards,1 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front axle | Dena 6.5 tons |
| Rear axle | Dena 11.5 tons |
| Tire specification | |
| Tire specification | 10.00R20 18PR |
| Garbage compactor box | |
| Volume | 10cbm |
| Raw material | T700L, side is 5mm, and bottom is 5mm. |
| Loading Method | Rear loader, waste bins flipover mechanism, can match 2 units 240 L, or 1 unit 180L and 1 unit 300L waste bins |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
Tired of overflowing bins and endless collection rounds? Meet CLW Group’s game-changing garbage compactor truck – engineered to tackle urban waste with unmatched efficiency. Built on Dongfeng’s battle-tested 4×2 chassis, this 10cbm compressed garbage truck transforms messy realities into clean streets. For municipalities and contractors alike, this Dongfeng garbage compactor truck isn’t just machinery – it’s your frontline warrior against waste.
Built Tough for Daily Grind
Reliable Muscle: Dongfeng’s B170 33 engine (170hp/125kW) powers through tight streets and steep hills without breaking stride
Operator-Friendly Control: Smooth DF6S900 6-speed shifting + power steering make 8-hour shifts feel effortless
Survivor Specs: 6.5-ton front axle + reinforced 10.00R20 tires laugh off potholes and curbs
Safety First: Air brakes with vacuum assist deliver rock-solid stops near schools and markets
The Compression Revolution
This garbage compression truck doesn’t just collect trash – it dominates it:
→ 10cbm Beast Mode: Compacts 0.6-0.8t/m³ – squeezing 3x more waste per trip than standard trucks
→ Bin-Smart Loading: Rear-loader flips 240L/300L bins effortlessly – no more manual lifting
→ Armored Build: 5mm T700L steel body shrugs off corrosive leaks and debris impacts
→ One-Button Unloading: Hydraulic push plate ejects compacted waste in 15 seconds flat
Watch how it works: Bins flip → waste crushes → space magically reappears. Rain or shine, this trush compactor truck turns chaotic routes into optimized loops.
Why Cities Choose CLW:
Cost Slayer: 40% fewer trips = lower fuel + labor bills
No Bin Left Behind: Handles mixed bin sizes (180L + 300L simultaneously)
Dongfeng Durability: 200,000+ km chassis lifespan
Zero Leaks: Sealed compaction chamber contains odors and fluids
Make It Your Secret Weapon
Add GPS routing, odor-control systems, or hybrid power – we’ll tailor your CLW Group garbage compactor truck for tomorrow’s challenges.
