DongFeng
CLW
CLW5180CT9
Product Description：
Meet the Auto Haul Pro: Dongfeng 4×2 Car Carrier Truck – Where Precision Meets Protection
Tired of scratched bumpers or struggling with oversized SUVs? Our CLW Group car carrier truck redefines vehicle logistics. Built on Dongfeng's rock-solid 4×2 chassis, this center axle car transporter masters dealership runs, auction pickups, and fleet relocations with surgical precision. When your reputation rides on flawless delivery, this safety car carrier truck becomes your trusted partner.
Power Meets Control: Highway-Tested Chassis
Powered by a torque-rich B210 33 engine (210hp/155kW), this car hauler truck tackles steep ramps and city streets without breaking a sweat. Its optimized 7.1m wheelbase and 14.8/12° approach/departure angles glide into tight loading bays effortlessly. With smooth WLY 8-speed shifting and responsive power steering, maneuvering feels like driving a delivery van – not a 12m giant. Heavy-duty axles (6.5t front/11.5t rear) and grippy 295/60R22.5 tires (plus spare) handle uneven lots, while air brakes anchor loads securely on downhill slopes.
Engineering Brilliance: The 2-Level Advantage
This multi-level vehicle transporter doesn't just carry cars – it cradles them:
→ Generous Clearance: 1.95m between decks fits jacked-up SUVs and minivans (no more roof scrapes!)
→ Expandable Reach: Upper deck extends to 13.5m (12m + 0.5m front/1m rear extensions)
→ Hyde Hydraulic Magic: 10 Italian oil cylinders lift 4-ton vehicles like feathers
→ Knee-Friendly Loading: 0.9m lower deck height saves backs and time
Built with low-alloy high-strength steel, the deck laughs off decades of loading ramps slamming down.
Why This Carrier Outperforms:
Zero-Damage Guarantee: No more insurance claims for scratched paint
Parking-Lot Nimble: Turns tighter than most box trucks
Dealer's Dream: Haul 8 sedans or 4 SUVs + 3 sedans in one trip
CLW Toughened: Stress-tested welds survive potholed auction yards
Grow Your Capacity
Add hydraulic extensions, winch systems, or LED load lights – we'll customize your CLW Group car carrier truck for tomorrow's challenges.
Main Technical Parameters：
| Main Technology Parameter | |
| Model Name | CLW Group Dongfeng 4x2 Car Transport Truck |
| Driving Type | 4x2 |
| Color | white and black or based on client’s request. |
| Number of Cabs | 2 |
| Weights | |
| GVW(kg) | 18000 |
| Curb Weight(kg) | 9350 |
| Dimensions | |
| Wheelbase(mm) | 7100 |
| Front/Rear Overhang(mm) | 1430/3470 |
| Approach/Departure Angle | 14.8/12 |
| Overall Dimension(mm) | 12000*2550*3900 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | B210 33 |
| Engine Type | Common rail system;EGR+DOC+DPF+SC |
| Max.Output(kw) | 155(210hp) |
| Drive Line | |
| Transmission | WLY Brand；8 forwards,2 reverse gear |
| Steering | Power steering |
| Brake | Air brake system |
| Axle | |
| Axle | 6500/11500 |
| Tire Specification | |
| Tire Specification | 295/60R22.5 18PR; 6+1spare tire |
| Front Wheel Track(mm) | 1860 |
| Rear Wheel Track(mm) | 1820 |
| Upper Body Configuration | |
| Platform Organ | |
| Upper Deck Length | 12 meter |
| Lower Deck Length | 9.8 meter |
| Platform Power Stroke(mm) | 2680 |
| Min Angle(°) | 7.6 |
| Max Lifting Capacity(kg) | 3000 |
| Winch Rating Pulling Capacity(kg) | 4000 |
| Length of Steel(m) | 21 |
| Hoisting Organ | |
| Max Under Hoisting Capacity(mm) | 1300 |
| Rating Under Hoisting Capacity(mm) | 1005 |
| Fully Extended Max Under Hoisting Capacity(mm) | 700 |
| Rating Under Pulling Capacity(kg) | 5000 |
