Technical Specifications of the CLW Group 10cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Group Dongfeng 4x2 10cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Weights | |
| GVW(kg) | 8275 |
| Curb weight(kg) | 6350 |
| Dimensions | |
| Wheelbase(mm) | 3800 |
| Overall Dimension(mm) | 8210*2500*3390 |
| Max speed(km/h) | 95 |
| Engine | |
| Engine model | CA6DF2D-18 |
| Emission standard | Euro 2 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 6.557 |
| Max. output (kw) | 132(180hp) |
| Drive Line | |
| Transmission | FAST 8JS85E; 8 forwards,2 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front axle | Dena 3.3 tons |
| Rear axle | Dena 4.975 tons |
| Tire specification | |
| Tire specification | 7.50R16LT 16PR |
| Garbage compactor box | |
| Volume | 10cbm |
| Raw material | T700L, side is 5mm, and bottom is 5mm. |
| Loading Method | Rear loader, waste bins flipover mechanism, can match 2 units 240 L, or 1 unit 180L and 1 unit 300L waste bins |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 0.6-0.8t/m³ |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
Product Description：
Tired of bulky trucks struggling in tight neighborhoods? Meet CLW Group's agile garbage compactor truck – engineered to crush urban waste challenges. Built on FAW’s nimble 4×2 chassis, this 10cbm compressed garbage truck transforms cluttered alleys and crowded suburbs into spotless zones. For cities battling space constraints, this garbage compression truck isn’t just equipment – it’s your secret cleanup weapon.
Power Meets Precision: Built for City Grids
Effortless Muscle: FAW's CA6DF2D-18 engine (180hp/132kW) tames steep hills and stop-start routes while sipping fuel
Driver's Dream: FAST 8-speed manual glides through gears + razor-sharp steering nails U-turns
Compact Champion: 3.8m wheelbase dances around parked cars and narrow lanes
Survivor Specs: 10.00R20 tires eat potholes for breakfast; air brakes deliver panic-free stops
Compaction Genius: Work Smarter, Not Harder
This trush compactor truck doesn't just collect – it revolutionizes:
→ Space Wizardry: 0.6-0.8t/m³ compaction crams 3x more waste per run
→ Bin Boss: Rear-loader flips mixed bins (180L+300L) – no wrestling, no spills
→ Smart Control Hub: Dual-side panels + PLC system = one-button cycles or manual finesse
→ Armored Core: 5mm T700L steel laughs off corrosive sludge and impacts
Watch the magic: Bins flip → hydraulic press crushes → ejector plate clears debris in 20 seconds flat. This garbage transfer truck turns chaotic routes into clockwork.
Why Cities Choose CLW:
Route Killer: Compact size hits 30% more stops per shift
Zero Training Needed: Half-auto controls simplify rookie onboarding
FAW Toughness: 300,000km+ proven chassis lifespan
Spill Proof: Sealed compaction traps odors and leachate
Tailor Your Cleanup Crew
Add GPS routing, solar compactors, or CCTV monitoring – we'll customize your CLW Group garbage compactor truck for tomorrow's challenges.
