HOWO
CLW
CLW5180OT4
Meet the Urban Workhorse: HOWO 4×2 8cbm Oil Tank Truck – Precision Delivery Where You Need It
Tired of oversized tankers struggling in city limits? Our CLW Group oil tank truck redefines efficiency for local fuel distribution. Built on HOWO's agile 4×2 chassis, this compact 8cbm oil tanker delivers gasoline, diesel, and specialty fuels to gas stations, construction sites, and farms with unmatched maneuverability. When space matters as much as capacity, this HOWO oil tank truck is your smart solution.
Nimble Yet Capable: City-Friendly Performance
Powered by a fuel-efficient ISF3.8s3154 engine (154hp / 115kW), this oil transport truck tackles urban routes without compromise. Its optimized 3800mm wheelbase and tight 6950mm length slip through narrow streets effortlessly. With smooth WLY 5-speed manual shifting and responsive power steering, navigating congested areas feels like driving a utility van – not a heavy-duty fuel tank truck. Reinforced axles (4,285kg front / 7,710kg rear) and durable 8.25R20 tires (plus spare) handle rough access roads, while disc brakes ensure instant stops near pedestrians or traffic.
Big Safety in a Compact Package
The 8.05cbm carbon steel tank (Q235-grade, 5mm walls) packs serious innovation:
Dual-Product Flexibility: Two segregated compartments carry different fuels safely
Spill-Proof Design: 4mm breakwater plates prevent surge; dual 20-inch manholes with vacuum vents
15-Minute Turnarounds: Bottom-loading pneumatic valves + gravity discharge via 4" aluminum pipes
Theft-Resistant: Lockable outlet boxes hide API adapters from tampering
Optional aluminum alloy construction available for chemical transport. This fuel transport truck meets ADR standards without sacrificing practicality.
Why Choose This Compact Tanker?
→ Urban Access Master: 18/26° approach/departure angles conquer steep driveways
→ No More Waiting: Gravity discharge unloads 8cbm 60% faster than pump systems
→ Multi-Fuel Efficiency: Haul gasoline and diesel in one trip
→ HOWO Reliability: Proven chassis backed by CLW Group engineering
Tailored to Your Needs
Customize tank material, add safety systems, or integrate telematics – we'll build your perfect oil tank truck.
| Main Technology Parameter | |
| Model Name | CLW Group HOWO 4x2 Oil Tank Truck |
| Driving Type | 4x2 |
| Color | White or based on client’s request. |
| Number of Cabs | 3 |
| Weights | |
| GVW(kg) | 11995 |
| Rated Payload Weight(kg) | 6680 |
| Curb Weight(kg) | 5120 |
| Dimensions | |
| Wheelbase(mm) | 3800 |
| Front/Rear Overhang(mm) | 1180/1970 |
| Approach/Departure Angle | 18/26 |
| Overall Dimension(mm) | 6950*2350*2800 |
| Max Speed(km/h) | 89 |
| Engine | |
| Engine Model | ISF3.8s3154 |
| Engine Type | Water-cooled,four-stroke,with exhaust valve braking, direct injection turbocharged with intercooling |
| Max.Output(kw) | 115kw(154hp) |
| Drive Line | |
| Transmission | WLY Brand; 5 forwards,1 reverse gear |
| Axle | |
| Axle(kg) | 4285/7710 |
| Tire Specification | |
| Tire Specification | 8.25R20 16PR; 6+1 spare tire |
| Front Wheel Track(mm) | 1776 |
| Rear Wheel Track(mm) | 1595 |
| Number of Leaf Springs | 3/3+2 |
| Upper Body | |
| Fuel Tank | |
| Capacity(cbm) | 4600*1930*1200mm; 8.05cbm |
| Tank Material | Carbon steel Q235(Aluminum alloy) |
| Filling Medium | Gasoline,Diesel Or Other Loading Medium |
| Thickness(mm) | Head is 4mm; tank is 5mm ;separated plate is 5mm;breakwater plate is 4mm |
| Compartments | 2 |
| Manhole | 1. Two manholes with a diameter of 20 inches and 20-inch manhole covers; a 10-inch filling/venting port. The pressure vacuum vent and emergency vent are included in the manhole assembly. 2. Protective covers are provided for the manholes. |
| Discharge System | Bottom loading and gravity discharge system: 1. Bottom valve: There are 2*4-inch pneumatic bottom valves at the bottom of the tanker. 2. 4-inch aluminum alloy pipeline 3. There are 2*4-inch API adapters on the right side of the tanker, equipped with aluminum dust covers. Horizontal installation. 4. All outlets are inside the aluminum alloy box. 5. The outlet box is equipped with a collapsible door with a lock. |
| Vapor Recovery System | 1. Two sequential pneumatically controlled air vents. 2. A 3-inch aluminum alloy pipeline from the two manholes to the middle bottom of the tank. 3. One vapor recovery adapter is installed on the right side of the middle bottom of the tank. |
