ISUZU FVZ 10-Wheel 30-Ton T700 Dump Truck – Heavy-Duty Power for Construction & Mining

The ISUZU FVZ 6x4 Dump Truck (30 tons) is a high-performance heavy-duty vehicle designed for large-scale construction, mining, and infrastructure projects. With engine options from 380hp to 520hp, a strong T700 steel dump box, and ISUZU's globally trusted engineering, this dump truck delivers outstanding reliability, durability, and efficiency in tough working environments.

Strong ISUZU Chassis & Cabin

• Durable 6x4 Drive Axle – Provides excellent traction and stability for heavy loads on rugged terrain.

• Comfortable ISUZU Cabin – Spacious flat-roof design with 3 seats, air-conditioning, FM radio, CD player, and ergonomic controls for long working hours.

• Safety First – Reinforced cabin with reliable visibility and stable steering ensures secure operation.

Powerful Engine & Transmission

• Engine Options – ISUZU 6WG1-TCG62 turbocharged diesel engine with 380hp, 420hp, 460hp, or 520hp options.

• Displacement – 11.99L, EURO 5 emission standard for global compliance.

• High Output – Up to 383kW / 520hp and max speed 95 km/h for efficient hauling.

• Transmission – Matched with ISUZU's proven gearbox for smooth shifting and reliable torque delivery.

Heavy-Duty Dump Box

• Large Capacity – Box dimensions 6000 × 2350 × 800 mm with 15 cbm volume, suitable for gravel, sand, coal, ore, and construction waste.

• High-Strength Steel – T700 material with 6mm side walls and 8mm bottom, ensuring durability against impact and wear.

• Hydraulic System – Equipped with 180 hydraulic cylinder for stable lifting and fast unloading.

• Customizable Design – Side doors and color can be built according to customer requirements.

Key Specifications

• Overall Dimensions: 9995 × 2450 × 3340 mm

• Curb Weight: 9420 kg

• Payload Capacity: 20,000 kg (30 tons GVW)

• Wheelbase: 4500 + 1300 mm

• Tires: 12R22.5 18PR, total 10+1 spare

• Manufacturer: ISUZU Motors Co., Ltd. (chassis) & ChengLi Special Automobile Co., Ltd. (dump body)

Advantages of ISUZU FVZ 30-Ton Dump Truck

• Reliable Performance – ISUZU engine ensures power and efficiency under heavy workloads.

• Durable Build – T700 high-strength steel dump box extends service life.

• Fuel Efficiency – EURO 5 compliant engine lowers emissions and fuel consumption.

• Wide Applications – Suitable for mining, road construction, urban infrastructure, and bulk material transport.

• Global Support – Backed by ISUZU's worldwide service network.

FAQ (Frequently Asked Questions)

Q1: What is the loading capacity of the ISUZU FVZ dump truck?
A: The truck can carry up to 30 tons with a dump box volume of 15 cubic meters.

Q2: What engine power options are available?
A: The ISUZU FVZ dump truck comes with 380hp, 420hp, 460hp, and 520hp engine options to suit different job requirements.

Q3: What materials can the dump truck transport?
A: It is suitable for sand, gravel, coal, ore, construction debris, and bulk materials.

Q4: Is the dump box durable enough for mining use?
A: Yes. The dump box is made of T700 high-strength carbon steel (6mm side, 8mm bottom), designed for heavy-duty applications.

Q5: Can the truck be customized?
A: Yes. Box design, side doors, color, and cabin options can be customized according to client requirements.

Q6: What is the maximum speed of the truck?
A: The maximum speed is 95 km/h, suitable for both highway and site operations.
