Production Description:
Isuzu ELF KV600 4x2 Dump Truck
Chassis & Mobility
Engineered for durability, this Isuzu dump truck utilizes the robust ELF KV600 chassis, ensuring superior stability and long-term reliability. Fitted with 7.50R16LT 14PR reinforced tires, it effortlessly handles uneven terrain and heavy loads while maintaining traction across diverse road surfaces. Despite its substantial capabilities, the truck’s streamlined dimensions (7025×2410×2440mm) allow nimble operation in tight urban zones or confined worksites.
Power & Efficiency
At its core lies the 4KH1CN6HB engine, generating 132 HP (97kW) to tackle demanding hauling tasks with ease. The engine balances raw power for steep climbs and steady high-speed performance, backed by proven fuel efficiency to lower operational expenses. Market-tested reliability ensures minimal downtime, even under prolonged use, reducing maintenance frequency and costs.
Cargo Box & Flexibility
The self-dumping steel cargo box (5175×2300×380mm) combines ruggedness with practicality, featuring 3mm sidewalls and a 4mm reinforced base for heavy-duty use. Dual 150mm hydraulic cylinders enable swift, stable unloading, while customization options include:
- Adjustable steel thickness to match load requirements.
- Optional side-access door for simplified loading.
- Tailored color schemes (cargo box and cab) for brand alignment or visual preference.
Versatile Application
From compact construction sites to urban logistics, this truck excels in adaptability. Its blend of power, agility, and user-focused design ensures efficient material handling across varied environments, all while prioritizing durability and cost-effectiveness.
Main Technical Parameters：
| Vehicle Description | Brand | CLW |
| GVW(kg) | 8280 |
| Curb Weight(kg) | 3250 |
| Loading Weight(kg) | 4835 |
| Overall Dimension(mm) | 7025*2410*2440 |
| Wheelbase(mm) | 3815 |
| Axle Load(kg) | 2580/4720 |
| Top Speed(km/h) | 105 |
|
| Chassis Brand | QL |
| Chassis Model | QL1080BUKA |
| Cabin | Single,LHD,with A/C |
| Engine | Model | 4KH1CN6HB |
| HP | 132 |
| Emission Standard | Eu 5 |
| Displacement/Output(ml/kw) | 2999/97 |
| Fuel Type | Diesel |
| Maximum Torque(N·m) | 290 |
| Gearbox | ISUZU MYY-6s 6Forward/1Reverse Gear |
| Tyre | 7.00R16LT 14PR |
|
| Dump | Box Dimension(mm) | 5175*2300*380 |
| Box | Manufacturers | ChengLi Special Automobile Co.,Ltd |
| Volume(cbm) | 4.5 |
| Configuration(mm) | side:3,bottom:4 |
| Material | Carbon steel |
| Side Door | According to costomer |
| Cabin | Brand | Isuzu |
| Model | Flat proof |
| Seat | 3 |
| Color | According to costomer |
