Shacman
CLW
CLW5180WS1
The Shacman 6x4 17.15cbm Watering Truck is designed for professional water transport, road maintenance, and dust control operations. Powered by the WP10.340E22 340HP diesel engine, it delivers strong torque, superior fuel efficiency, and excellent adaptability to both city and industrial work. Built on Shacman's durable chassis and assembled by CLW Group, this water tanker truck ensures long-term reliability under demanding working conditions.
Its 17.15 cubic meter tank, constructed from high-strength carbon steel or optional stainless steel, guarantees lasting durability and resistance to corrosion. The vehicle is equipped with front, side, and rear sprinklers, capable of covering areas wider than 14 meters, while the rear water cannon provides a shooting range of over 28 meters, ideal for firefighting or long-distance watering.
Whether used for municipal maintenance, landscaping, or construction site dust suppression, this Shacman water truck combines efficiency, flexibility, and safety to deliver reliable performance every day.
Powerful Performance:
Equipped with a 340HP WP10.340E22 engine and 10-speed transmission for exceptional torque and efficiency.
Large-Capacity Tank:
17.15m³ effective volume with 5mm-thick steel construction ensures durability and stability.
Multi-Functional Spraying System:
Includes front sprinklers, side sprays, and a rear cannon with >28m range for diverse applications.
Efficient Water Pump System:
High-pressure pump with >6m suction lift for rapid water intake and strong output.
Flexible Customization:
Options for fog cannon system, stainless steel tank, or upgraded components to fit different project needs.
Operator-Friendly Design:
Ergonomic controls, dual-side valves, and rear working platform for easy operation and maintenance.
| Item | Specification |
|---|---|
| Brand | CLW / Shacman |
| Driving Type | 6x4 |
| GVW (kg) | 25,000 |
| Curb Weight (kg) | 11,130 |
| Overall Dimension (mm) | 10,270 × 2,550 × 3,260 |
| Wheelbase (mm) | 4,375 + 1,400 |
| Axle Load (kg) | 7,500 / 13,000 |
| Top Speed (km/h) | 89 |
| Engine Model | WP10.340E22 |
| Horsepower (HP) | 340 |
| Emission Standard | Euro 3 |
| Displacement / Power (ml/kw) | 9726 / 250 |
| Fuel Type | Diesel |
| Gearbox | 10 Forward / 2 Reverse |
| Tire | 11.00R20 18PR (10+1 spare) |
| Tanker Material | Carbon Steel / Stainless Steel |
| Tank Capacity (m³) | 17.15 effective |
| Thickness (mm) | 5 |
| Spraying Width | >14m |
| Water Cannon Range | >28m |
| Pump Suction Lift | >6m |
Q1: What is the main use of the Shacman 6x4 Watering Truck?
A1: It is primarily used for road cleaning, dust suppression, landscaping irrigation, and emergency firefighting in cities and industrial areas.
Q2: Can the tank material be customized?
A2: Yes, you can choose between carbon steel or stainless steel, depending on your operational environment and budget.
Q3: What's the water tank capacity of this model?
A3: The effective capacity is 17.15 cubic meters, suitable for large-scale watering operations.
Q4: Does it support fog cannon installation?
A4: Yes, optional fog cannon systems can be integrated for enhanced dust suppression.
Q5: What's the maximum water spraying distance?
A5: The rear water cannon can spray water over a distance of more than 28 meters.
Main technical parameters：
| Vehicle Description | Brand | CLW |
| GVW(kg) | 25000 | |
| Curb Weight(kg) | 11130 | |
| Overall Dimension(mm) | 10270*2550*3260 | |
| Wheelbase(mm) | 4375+1400 | |
| Axle Load(kg) | 7500/13000 | |
| Top Speed(km/h) | 89 | |
| Chassis Brand | Shacman | |
| Chassis Model | SX5255GJBJR384 | |
| Cabin | Single,LHD,with A/C | |
| Engine | Model | WP10.340E22 |
| HP | 340 | |
| Emission Standard | Euro 3 | |
| Displacement/Output(ml/kw) | 9726/250 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2200 | |
| Maximum Torque(N·m) | 1250 | |
| Maximum Torque Speed(rpm) | 1400-1600 | |
| Gearbox | 10Forward/2Reverse Gear | |
| Tyre | 11.00R20 18PR | |
| Tanker Description | Actual Volume(cbm) | 18.03 |
| Effective Volume(cbm) | 17.15 | |
| Tanker Material | Carbon Steel,Stainless Steel,According to Customer needs | |
| Thickness(mm) | 5 | |
| Standard configuration | Equipped With | |
| 1.Front Sprinkler(rear and side,sprinkling width>14m) | ||
| 2.Rear Working Platform With Water Cannon(range>28m) | ||
| 3.Pump(suction Lift>6m) | ||
| 4.Fire Valve,Water Valve,and Filter Gauze | ||
| Optional Configuration | 1.Fog Cannon Could Be Available | |
| 2.Tanker Material Could Be Customized | ||
Other features:
- Installed sprinkling music reminder device: It can emit a music prompt sound during operation to remind pedestrians and vehicles to pay attention and avoid, ensuring operation safety.
- Installed water level gauge: It is convenient for the operator to know the water level in the tank in real time so as to replenish the water source or stop the operation in time to avoid situations such as empty tanks or overflow.
- With fire-fighting interface: It can take in water through the fire hydrant, has an auxiliary fire-fighting function, and can be used as a fire-fighting equipment in emergency situations, increasing the multifunctionality and emergency response capability of the vehicle.
