Shacman L3000
CLW
CLW5180ROF6
Product Description:
Shacman Roll On Off Truck – Versatility Redefined for Modern Waste Management
Built to Handle Any Load, Anywhere
The Shacman Roll On Off Truck is a game-changer for waste collection, construction debris removal, and industrial material transport. Designed for contractors, municipalities, and recycling centers, this CLW Group Hook Lift Truck streamlines operations with its rapid bin-swapping system. Whether hauling 2cbm to 18cbm containers for urban trash collection or managing bulky construction waste, its hydraulic precision and adaptability make it indispensable for dynamic, high-volume workflows.
Power and Precision: Chassis & Performance
Built on Shacman’s rugged chassis, this hooklift truck balances strength with agility. The WP6.210E32 engine delivers 155kW (210hp) of reliable power, optimized for heavy loads and challenging terrains. Paired with a FAST-brand manual transmission (8 forward + 2 reverse gears), drivers maintain full control over torque and speed, even on steep inclines. Reinforced 6.5-ton front/11-ton rear axles and 10.00R20 18PR tires (10+1 spare) ensure stability under maximum payloads, while the air brake system with vacuum pump guarantees safety during frequent stops. With a 19°/10° approach/departure angle and power steering, navigating tight job sites or narrow streets becomes effortless.
Smart Hydraulic Engineering: Upper Structure
The CLW Group Roll Off Dumpster Truck features a hydraulic hook lift system engineered for speed and reliability. High-tensile steel chains, imported hydraulic cylinders, and premium sealing materials ensure smooth, leak-free operation. The dual lifting cylinders beneath the container enable seamless self-dumping, while hydraulic rear stabilizer legs lock the truck in place during loading, preventing shifts and enhancing safety.
Unmatched Flexibility for Diverse Needs
Choose from trapezoidal, boat-shaped, or square bins (above-ground or underground compatible) to match specific project requirements. The system effortlessly swaps containers in minutes, minimizing downtime between tasks. Containers are built with reinforced walls and corrosion-resistant coatings, ideal for harsh waste materials or industrial use.
Why Choose This Shacman Garbage Truck?
From Shacman's robust engineering to CLW Group's expertise in waste solutions, this roll on off truck excels in durability, efficiency, and operator convenience. Its modular design reduces maintenance costs, while the rapid bin-swap capability maximizes productivity across multiple sites. Whether servicing compact urban neighborhoods or sprawling industrial zones, this garbage transfer truck is built to adapt—ensuring your operations stay ahead of the curve.
Technical Specifications of the CLW Group 12cbm garbage compactor truck：
| Main Technology Parameter | |
| Model Name | CLW Brand Shacman L3000 4x2 12cbm Garbage Compactor truck |
| Driving Type | 4x2 |
| Color | White color or based on client’s request. |
| Weights | |
| GVW(kg) | 18000 |
| Rated payload weight(kg) | 7700 |
| Curb weight(kg) | 10170 |
| Dimensions | |
| Wheelbase(mm) | 4500 |
| Overall Dimension(mm) | 7250*2550*3160 |
| Max speed(km/h) | 89 |
| Engine | |
| Engine model | WP6.210E32 |
| Emission standard | Euro 3 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 6.23 |
| Max. output (kw) | 155(210hp) |
| Drive Line | |
| Transmission | Fast Brand;8 forwards,2 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Air brake with vacuum pump |
| Axle | |
| Front axle | Dena 6.5 tons |
| Rear axle | Dena 11 tons |
| Tire specification | |
| Tire specification | 10.00R20 18PR |
1. Garbage Bin with different size options of waste collection truck: 2cbm to 18cbm.
2. Hydraulic Control Loading & Unloading System.
3. Different shapes of roll on roll off waste truck bins such as trapzoid,boat-shape,square shape and so on and divided into above-ground and under-ground type.
4. High-tensile steel chains: imported hydraulic oil cylinder and sealing material.
5. Lifting oil cylinder: double oil cylinder under garbage box,so garbage box can be lifted and self-dumped.
6. Double rear landing leg controlled by hydraulic multi-way valve to stablise truck.
