ISUZU
CLW
CLW5180CST2
Traditional box trucks can slow down loading because rear doors limit access and require space to open. This curtain side design solves that by allowing the side tarpaulin curtains to slide open, giving wide access from either side of the vehicle. It’s especially practical at busy loading bays, warehouses, and city delivery points where time and space matter.
With an overall size of 10,000 × 2,550 × 3,990 mm and a cargo body size of 7,600 × 2,500 × 2,620 mm, this truck balances cargo capacity with everyday maneuverability. The rated loading weight is 8.75 tons (GVW 18,000 kg, curb weight 9 tons), suitable for regular distribution tasks that require steady payload performance without stepping into heavier multi-axle configurations.
The truck is equipped with the ISUZU 6HK1-TCG61 diesel engine:
240 HP (177 kW) power output
850 N·m max torque
7.79 L displacement
Euro 6 emission standard
It pairs with a FAST manual gearbox (8 forward + 1 reverse) for dependable control under load. The 5,800 mm wheelbase, 6,500/11,500 kg axles, and 295/80R22.5 tires (6 + 1 spare) support stable handling in daily freight operations. The listed max driving speed is 89 km/h, and the fuel tank is 200 liters.
The cargo body is built with a functional material mix for strength and usability:
Front plate: 5mm carbon steel
Side plate: 3mm flat aluminum
Floor: 25mm transport plywood
Curtain: PVC coated awning (tarpaulin)
This structure supports common logistics needs such as pallet handling, strapped cargo, and frequent loading/unloading cycles, while the curtain system improves access flexibility when docking space is limited.
The truck uses an ISUZU FVR cabin (one and half row) with 3 passenger capacity and air conditioning, supporting driver comfort during multi-stop delivery routes.
Palletized goods distribution (warehouse to retail / regional delivery)
Industrial supplies and machinery parts transport
Logistics operations requiring frequent forklift side loading
Mixed cargo where side access improves handling efficiency
Routes with tight loading bays where rear-only loading is inconvenient
Curtain side access: Slide-open curtains enable side loading from either side
Efficient cargo handling: Helps reduce loading/unloading time in multi-stop work
Balanced payload & size: 8.75-ton rated loading weight with practical overall dimensions
Reliable powertrain: 6HK1-TCG61 240HP, 850 N·m, FAST 8-speed manual
Euro 6 compliance: Meets Euro 6 emission standard (as listed)
Stable chassis setup: 5,800 mm wheelbase, 6,500/11,500 kg axles, 295/80R22.5 tires
Body material spec is clear: 5mm carbon steel front, 3mm aluminum sides, 25mm plywood floor
Cabin comfort: 3 seats + A/C for daily operation
The ISUZU FVR Curtain Side Cargo Truck produced by CLW Group has been supplied to international markets for logistics, freight forwarding, and distribution operations. It is widely chosen for its balance of payload capacity, ease of loading, and dependable ISUZU mechanical performance in daily commercial use.
1) What is the rated loading weight of this truck?
The listed loading weight is 8.75 tons.
2) What are the overall dimensions of the vehicle?
10,000 × 2,550 × 3,990 mm.
3) What is the cargo body (cargo dimension) size?
7,600 × 2,500 × 2,620 mm.
4) Which engine model is used, and what is the power output?
ISUZU 6HK1-TCG61, 240 HP (177 kW), 7.79 L, max torque 850 N·m.
5) What is the emission standard?
The listed emission standard is Euro 6.
6) What transmission does it use?
FAST manual gearbox, 8 forward + 1 reverse.
7) What tires are fitted?
295/80R22.5, 6 tires + 1 spare.
8) What is the fuel tank capacity and max driving speed?
Fuel tank: 200 liters. Max driving speed: 89 km/h (listed).
9) What materials are used in the cargo body structure?
Tarpaulin: PVC coated awning; front plate: 5mm carbon steel; side plate: 3mm flat aluminum; bottom plate: 25mm transport plywood.
Main Technical Parameters:
| CLW Group ISUZU FVR Curtain Side Truck | ||
| General | ||
| Overall Dimension | 10000x 2550 x 3990 mm | |
| Gross Vehicle Weight | 18000 kg | |
| Curb weight | 9tons | |
| Loading Weight | 8.75tons | |
| Cabin | Isuzu FVR cabin,one and half row,3 Passenger Allowed, with A/C | |
| Chassis | ||
| Wheel Base | 5800mm | |
| Engine | Type | Watering Cooling, Four Stroke, 6 Cylinder in Line, Direct Injection. Diesel Engine, with ABS. |
| Model | Isuzu 6HK1-TCG61 | |
| Horse Power | 240HP/177kW | |
| Displacement | 7.79L | |
| Max torque | 850N.m | |
| Emission standard | Euro 6 | |
| Gearbox | FAST, Manual, 8 Forward & 1 Reverse Gear | |
| Axle | 6500/11500kg | |
| Front/rear overhang | 1370/2830mm | |
| Front/rear track | 2060/1855mm | |
| Max Driving Speed | 89 km/h | |
| Tire | 295/80R22.5, 6 pieces with 1 spare tire | |
| Speed Ratio | 4.555 | |
| Fuel tank | 200 Liters | |
| Upper | ||
| Cargo dimension | 7600*2500*2620mm | |
| Cargo loading | 9tons | |
| Tarpaulin material | PVC coated awning | |
| Front plate material | 5mm carbon steel | |
| Side plate material | 3mm flat aluminum | |
| Bottom plate material | 25mm thickness transport plywood | |
